IDNext971 Electronic Controller P/B | IDP29DB7S0000

Save 10%

Price:
Sale price108,71€ Regular price120,78€
Stock:
In stock

Description

The product is an electronic controller IDNext971 P/B. It is suitable for units using flammable refrigerants of category 2L or 3, such as R290 or R600. It offers innovative features.

Feature Detail
Part Number IDN971P9D307000
Operating Temperature -5...55°C
Storage Temperature -30…85°C
Ambient Humidity 10…90% RH (non-condensing)
Power Supply 230Vac
Power Draw 5.5 VA
Display Range -99.9…+99.9 °C / -999…+999 °C
N. Analogue Inputs 2
Analogue Inputs 2x PTC or NTC or Pt1000
N. Digital Inputs 1
Digital Inputs 1x SELV
N. Digital Outputs 2
Digital Outputs 1x SPST 2Hp 12(8)A 230Vac, 1x SPDT 0.5Hp 8(4)A 230Vac
Display LED 3 digits + sign
Resolution (0.1°C with decimal point) 0.1°C
Measurement Range NTC: -50.0…+110.0 °C, PTC: -55.0…+140.0 °C, Pt1000: -55.0...+150.0 °C
Accuracy NTC: better than 0.5% of full scale + 1 digit, PTC: better than 0.5% of full scale + 1 digit, Pt1000 [-55.0…+70.0°C]: better than 0.5% of full scale + 1 digit, Pt1000 [+70.0…+150.0°C]: better than 1% of full scale + 1 digit
Connectivity TTL port for connection to Unicard or ModBus monitoring device
N. Serial Ports 1
Serial Ports 1x TTL
Installation panel, 71x29mm
Accessories Unicard USB/TTL, Dongle BTLE/TTL
Functions Easy Map, Buzzer
Weight (g) Net 185
Width (L) Net 81mm
Height (Ht) Net 35mm
Depth (P) Net 60mm
Weight (g) Packaging 230
Width (L) Packaging 130mm
Height (Ht) Packaging 90mm
Depth (P) Packaging 50mm.
  • Refrigerated cabinets
  • Cabinets
  • Plug-in glass cabinets
  • Supermarket counters
  • Supermarkets
